商品の詳細:
|
| 正弦力（ピーク）: | 30KN | 衝撃力（ピーク）: | 60KN |
|---|---|---|---|
| 周波数範囲: | 5～2,600Hz | 変位（連続）: | 100mm |
| 最高。速度: | 1.8 m/s | Max. Acceleration: | 75 G |
| 1次共振周波数: | 2,400のHz | ||
| ハイライト: | Sine Wave Vibration Shaker Table,30KN Sine Wave Vibration Shaker,Structural Testing Sine Wave Vibration Shaker |
||
| Attribute | Value |
|---|---|
| Sine force (peak) | 30KN |
| Shock force (peak) | 60KN |
| Frequency range | 5～2,600 Hz |
| Displacement (continuous) | 100 mm |
| Max. Velocity | 1.8 m/s |
| Max. Acceleration | 75 G |
| 1st order resonant frequency | 2,400 Hz |
Electro-dynamic Vibration Testing Equipment is widely used in defense, aviation, aerospace, communications, electronics, automobiles, and home appliance industries. This system is designed for early fault detection, simulating actual working conditions, and structural strength testing.
| Component | Specifications |
|---|---|
| Shaker (Model# EDM-2000) |
|
| Power Amplifier (Model# VSA-H323A) |
|
| Horizontal Slip Table (Model# 30ST-600M) |
|
| Temperature range | 0-40℃ |
| Humidity range | 0-90% (no condensation) |
| Power requirements | 380V/3ph/50Hz, 40kVA |
| Compressed air pressure | 0.6 Mpa |
