商品の詳細:
|
| 材料: | 鋼鉄 | オプションの機能: | カスタマイズ可能な負荷容量と寸法 |
|---|---|---|---|
| キーワード: | 家具の試験機 | 力: | 電子 |
| テスト方法: | 動的および静的負荷テスト | 電源: | AC/DC |
| 使用: | 椅子 | タイプ: | テスト機器 |
| ユニットスイッチ: | gf、kgf、N、LBf、W、KN、T | 運転モード: | 可変的な頻度モーターおよびタイミング ベルト |
| 電源: | 電気 | LCDディスプレイ: | はい |
| 調節可能なアームレスト: | はい | ||
| ハイライト: | Environmental Wheelchair Test Chamber,High Temperature Wheelchair Test Chamber,Low Temperature Wheelchair Test Chamber |
||
| Temp. & Humid. Sensor | High precision PT100 Platinum resistance |
|---|---|
| Controller | Weintek |
| Display Function |
|
| Interface |
|
| Internal dimension(W*D*H) | 1200*2500*1500mm |
|---|---|
| External dimension(W*D*H) | 2500*3000*2500mm |
| Internal material | 1.2mm thickness SUS#304 stainless steel, mirror finished; |
| External material | 1.2mm thickness cold-rolled steel plate baking |
| Temperature range | -40℃ ~ + 100℃ |
|---|---|
| Temperature fluctuation | ±0.5℃ |
| Temperature uniformity | ≤2℃ |
| Temperature rate | 1℃/min in average (without loading) |
| 3℃/min in average (without loading) |
| Power source | Three-phase, 380V,50Hz |
|---|---|
| Power | 3 kw |
| Current | 18 A |
| Weight | Approx. 360kg |
| Compressor | Semi-Hermertically Sealed Germany Bock compressor |
|---|---|
| Refrigerant | R449A |
| Cooling method | Single-stage compression |
| Cooling method | Air-cooled flake condenser, cooling fan for heat dissipation |
| Heating system | Nichrome stainless steel heater |
| Sample tray | SUS#304 stainless steel 2 pieces |
| Testing hole | Diameter 50mm*2, Located left and right side, for sample connecting |
| Evaporator | Finned tube heat exchanger |
| Dry filter | Absorb the residual moisture and acidic substances in the refrigerant of the refrigeration system, and filter out solid particles, copper shavings, etc. in the system to protect the normal operation of the expansion valve and capillary tube, and prevent ice blocking and dirty blocking. |
| Door handle | Non-reaction, explosion-proof door handle, easy to operate, safe and reliable |
| Insulation | 100mm polyurethane rigid foam and 100mm high density glass fiber cotton |
